LMW proven spinning geometry enhances the quality and productivity. LMW Ringframes with robust design helps in less maintenance cost, machines with inbuilt Energy saving solution to ensure less Spinning cost and boosts Profitability to Spinners.

Features

• LR9A upto 1824 spindles helps in less space requirement, less humidification comparatively
• Hook Lock Low Decibel (HLLD) spindles with less Vibration & Noise
• In built Energy saver with IE4 main motor, Inverter Controlled IE3 suction motor,Inclined suction tube to improve effective suction
• 4Q-2M drive for drafting
• T-Flex drive system for quality consistency

Flexibility

• Ne range from 8s to 200s can be spun
• Machines with doffer and without doffer option available
• 16 step Speed pattern curve
• Ready to retrofit of Compact/SIRO system
• Spindle pitch 70mm & 75mm option available with lift options from 160 to 210mm
• Pneumatic load and Spring load both the options of Top arm are available

Automation

• Rapid doff system (<110sec doff time)
• Basket Tube loading system for ease of operation
• Yarn Breakage monitoring system & Roving stop motion available as optional
• Machine ready to merge with LMW Spin Connect system with an unique feature called Recipe management
• Power Consumption can be monitored through display
